Samlex Voltage Sensitive Relay 100A 12/24V

A small relay with an in built microprocessor that controls the charging between multiple batteries. Once the primary battery is charged the charge is paralleled and the auxiliary battery is charged.

• 12 & 24V Systems
• Max Alternator Amps: 100A
• Microprocessor Controlled
• Provides Priority for charging only the starter battery first
• Prevents excessive discharging of the starter battery
• Automatic detection of 12V or 24V DC systems
• Bi-Directional - If a battery charger is connected to auxiliary battery then starter battery will be charged.
• Over Voltage Protection - If exceeds 16V (32V) relay will shut off
• Battery Connection: 2 x M6 Studs / Other Connections: 6.3mm Spade
• Connects @ 13.2V (12V) / 26.4V (24V)
• Disconnects @ 12.8V (12V) / 25.6V (24V)
