Samlex DC-DC Voltage Step Up Convertor (12V-24V)

Features

• Advanced switchmode design
• Mount in almost any location
• Reverse polarity protected
• High efficiency
• Overvoltage protection
• Short circuit protected

Specifications

• Non-isolated: input and output have a common negative
• Input Voltage: 9-18V DC
• Output Voltage: 25V DC
• Output Stability: 1%
• Output current continuous: 25A
• Cooling: Passive
• Operating Temp: -10° to +40°
• Input/Output Connections: 3 x M6 Hole
• Dimensions (L x W x H): 335 x 163 x 64mm
